Up-Down Through-Floor Home Lift
Travels through a floor opening: no shaft, no pit, no machine room.
The lift
What the Up-Down is built for
It stands on the finished floor on its own column, so the building work is an opening and a circuit.
Two stops and two people, 250 kg.
It suits
- Two-storey houses, and bungalows with a finished basement
- Owners who want the least building work possible
- One person, or one person and a helper
Certified components
Certified motor and controller
Choose CSA, UL (cUL) or CE versions, with the certificates in the quote.
What that covers
Specifications
Up-Down at a glance
- Rated load
- 250 kg (550 lb)
- Capacity
- 2 people
- Travel
- Single floor
- Stops
- 2 floors
- Shaft (minimum)
- None — from a 950 × 1000 mm (37 × 39 in) footprint
- Pit depth
- None
- Speed
- 0.15 m/s
- Drive
- Screw-driven self-supporting column
- Door
- Open platform with safety gate
Shaft and pit sizes are minimums; local rules may require more. Every model needs a dedicated circuit, which we install.
FAQ
Up-Down questions
Do I need a shaft for a through-floor lift?
No, it runs on its own column through a framed opening in the floor.
How long does installation take?
The lift goes in within a couple of days, with the opening and circuit prepared beforehand.
Can it serve three floors?
No, two stops only; for more floors, look at the G1 or Q.
