Machine-room-less passenger elevator
Youjia G1 Home Elevator
No machine room and a pit from 150 mm, so it often sits on the existing slab.
The elevator
What the Youjia G1 is built for
Its gearless steel-belt drive sits inside the shaft, quieter than ropes and never oiled.
It carries three to four people or a wheelchair up to six floors, and returns to the nearest floor in a power cut.
It suits
- Houses with three or more floors, new build or retrofit
- A shaft of about 1.2 m (4 ft) square is available, or can be framed
- Owners who want an enclosed car and a quiet ride
Certified components
Certified motor and controller
Choose CSA, UL (cUL) or CE versions, with the certificates in the quote.
What that covers
Specifications
Youjia G1 at a glance
- Rated load
- 320 kg (705 lb)
- Capacity
- 3–4 people
- Travel
- Up to 15 m (49 ft)
- Stops
- 2–6 floors
- Shaft (minimum)
- 1200 × 1200 mm (47 × 47 in)
- Pit depth
- From 150 mm (6 in)
- Speed
- 0.4 m/s
- Drive
- Gearless traction, steel belt
- Door
- Automatic, side or centre opening
Shaft and pit sizes are minimums; local rules may require more. Every model needs a dedicated circuit, which we install.
FAQ
Youjia G1 questions
Does the G1 need a machine room?
No, the machine sits inside the shaft, so it needs only the shaft, a shallow pit and top-floor headroom.
Will the G1 fit on my existing basement slab?
Often, since the pit starts at 150 mm (6 in); the site survey checks your slab.
How many floors can the G1 serve?
Two to six stops, with up to 15 m (49 ft) of travel.
Will the Youjia G1 fit your house?
Send the floors and a photo of the space.
